Product Details:
Payment & Shipping Terms:
|
| Feature: | Ultra Light | Protection Level:: | IP40 |
|---|---|---|---|
| Certification: | CCC,CE,ETL,ROHS | Servicing: | Front/Rear |
| Max Hanging: | 20/10 | Max Stacking: | 20/10 |
| Color: | Full Color | Delivery Time: | 20days |
| Highlight: | hire led screen,LED video wall rental |
||
IP40 Ultra Light Rental LED Display With Good Heat Emission Capability
Rental LED Display Feature
1. Ultra-thin & ultra-light
2. Die -casting cabinets, high precision with seamless splicing
3. Standard cabinet size: 500x500mm, convenient for area calculation
4. Highly effective & quick for transportation and screen assembling
5. High brightness and be adjustable, meets the need of the changing requirement of customer in environment.
6. Good heat emission capability.
Parameters of BST-IRD-4.81
| SPECIFICATION | |||
| IRA-2 | IRA-3 | IRA-4 | |
| Physical Pitch | 2.97 | 3.91 | 4.81 |
| Pixel Configuration | SMD2121 | SMD2121 | SMD2121 |
| Pixel Density | 112,896 pixels/sqm | 65,536 pixels/sqm | 43,264 pixels/sqm |
| Module Dimensions (WXH)(mm) |
250X250 | 250X250 | 250X250 |
| Panel Dimensions(mm) | 500X500X75 / 500X1000X75 |
500X500X75 / 500X1000X75 |
500X500X75 / 500X1000X75 |
| No. of Modules Per Panel(WXH) |
2X2/2X4 | 2X2/2X4 | 2X2/2X4 |
| Physical Resolution of Module(WXH) |
84X84 | 64X64 | 52X52 |
| Physical Resolution of Panel(WXH) |
168X168/ 168X336 | 128X128/ 128X256 | 104X104/ 104X208 |
| Panel Material | Die-Casting Aluminum | Die-Casting Aluminum | Die-Casting Aluminum |
| Single Cabinet Weight |
8/14kg/panel | 8/14kg/panel | 8/14kg/panel |
| Processing | 16bit | 16bit | 16bit |
| Colours | 281 trillion | 281 trillion | 281 trillion |
| Contrast Ratio | 4,000:1 | 4,000:1 | 4,000:1 |
| Average Power Consumption |
64/128 W/panel | 64/128 W/panel | 64/128 W/panel |
| Max Power Consumption |
192/384 W/panel | 192/384 W/panel | 192/384 W/panel |
| Operation Temp/ Humidity |
—10℃-60℃ /10%-60% | —10℃-60℃ /10%-60% | —10℃-60℃ /10%-60% |
| Storage Temp/ Humidity |
—30℃-60℃ /10%-60% | —30℃-60℃ /10%-60% | —30℃-60℃ /10%-60% |
| Refresh Rate | >1920Hz | >1920Hz | >1920Hz |
| Brightess | ≥1,200nits | ≥1,200nits | ≥1,200nits |
| Horizontal Viewing Angle |
160° | 160° | 160° |
| Vertical Viewing Angle |
140° | 140° | 140° |
| Expected Lifetime | 100,000Hrs | 100,000Hrs | 100,000Hrs |
| Max Stacking | 20/10 | 20/10 | 20/10 |
| Max Hanging | 20/10 | 20/10 | 20/10 |
| Servicing | Front/Rear | Front/Rear | Front/Rear |
| IP Rationg (Front/Rear) |
IP 40/IP21 | IP 40/IP21 | IP 40/IP21 |
| Certification | CCC,CE,ETL,ROHS | CCC,CE,ETL,ROHS | CCC,CE,ETL,ROHS |
Rental LED Display Application:
Sports Stadium, Outdoor Signage and advertisement, Entertainment centers, Building facilities, Community centers, Amusement parks, Auto Parts and Maintenance shops etc.
Why choose BST
| 1. Our LED display signs have the ISO9001:2000 Quality System Certification; |
| 2. CE & RoHS Certification of our LED display signs; |
| 3. Excellent Technical Innovation; |
| 4. Contract Performance and Credibility; |
| 5. Price performance ratio; |
| 6. Modular LED display screens; |
| 7. LED displays with high brightness LED's; |
| 8. High ecperiences and know-how LED display products; |
| 9. Post sale assistance (after sale); |
| 10. Our LED display screens have a warranty up to 1-3 years (depending on configuration). |
| 11. Personalized sale and less than 24 hours response on all inquiries; |
