Stage-Ready & Beyond: ORA’s Modular LED Panels – Curved Configurations, Low Power, and Global Certifications Designed for outdoor stages, concerts, sports arenas, and commercial exhibitions

ORA Series LED Video Panel Product Introduction

Product Overview

The ORA Series LED video panel is engineered for outdoor rental and stage applications, combining high brightness, durability, and flexibility. With four pixel pitch options (2.6mm, 2.9mm, 3.9mm, 4.8mm), it caters to diverse requirements for image quality and budget. Featuring modular design, waterproof capabilities, and crash-proof protection, this series is an ideal solution for large-scale events, stage performances, and commercial exhibitions.

Key Features

1. Ultra-High Brightness & Superior Visual Performance

• 4500 Nits Brightness: Ensures vivid and clear visuals even under direct sunlight, perfect for outdoor environments.

• 16-bit Grayscale & 4000:1 Contrast Ratio: Delivers smooth color transitions and rich dark details for cinematic-quality displays.

• 7680Hz Refresh Rate: Eliminates motion blur, ensuring seamless playback for high-speed content and live broadcasts.

2. Full Outdoor Waterproof Design

• IP65/P54 Rating: Front panel is dustproof and waterproof (IP65), while the rear is protected against splashes (IP54), ideal for harsh weather.

• Waterproof Connectors: Outdoor-grade interfaces guarantee stable performance in rainy or humid conditions.

3. Flexible Installation & Curvilinear Assembly

• Concave/Convex Curvilinear Design: Supports 500x500mm and 500x1000mm panels for horizontal or vertical curved configurations, enabling creative stage setups.

• Lightweight Modular Structure: Each panel weighs only 8kg/14kg (two sizes), allowing rapid assembly and disassembly to boost efficiency.

4. Durability & Safety Protection

• Die-Casting Aluminum Panel: Resists corrosion and impact, ensuring long-term reliability.

• Crash-Proof Corners: Reinforced edges prevent damage during transportation and installation.

• 100,000-Hour Lifespan: Extended LED longevity reduces long-term operational costs.

5. Energy Efficiency & Stability

• Low Power Consumption: Average power usage as low as 64W/128W per panel (two sizes), with peak consumption at 384W.

• Wide Temperature Tolerance: Operates in -10°C to 60°C and stores safely in -30°C to 60°C, suitable for extreme climates.

6. Versatile Models for Diverse Needs

• Four Models for Targeted Applications:

  • ORA-2.6/2.9: High pixel density (147,456px/m², 112,896px/m²) for close-up viewing, ideal for stage backdrops and premium ads.

  • ORA-3.9/4.8: Cost-effective options for mid-to-long-distance displays, such as concert main screens and stadiums.

Technical Specifications

Conclusion

The ORA Series LED video panel redefines outdoor display standards with its exceptional brightness, waterproof design, flexible assembly, and rugged durability. Whether for music festivals, sports events, or commercial activations, its versatile pixel pitches and modular structure adapt seamlessly to any scenario. Backed by a 100,000-hour lifespan and global certifications, the ORA Series offers not only stunning visuals but also high cost-effectiveness and low maintenance, making it the ultimate choice for professional applications.
