Product Details:
Payment & Shipping Terms:
|
| Power Supply:: | AC 110/220V | Cabinet Material:: | Iron/Aluminum |
|---|---|---|---|
| LED Control System:: | Nova/Linsn | Working Humidity:: | 10~90% |
| Package: | Wooden Case | Lifetime:: | 100,000 Hours |
| Brightness: | >1200nits | Refresh Rate: | >1920hz |
| High Light: | advertising led display screen,led wall display screen |
||
Advertising Indoor Full Color P5mm LED Display Screen with Fixed Installation(HD)
Products Feature:
1.High and adjustable LED brightness can meet the demands of the changing requirement of customer in different environments.
2. No mosaic display due to excellent flatness and nice uniformity of light-emitting
3.Wide viewing angle and the horizontal angle can reach 120°m. The images display effect will not Change largely in the range.
4. Virtual pixel display screen can be adopted for outdoor displays to increase the resolution up to four times of real pixel, making the images softer and vivider.
5. LED Single-lamp maintenance with low cost.
6. Good heat dissipation capability because of the unique design of vent fan.
7. Environmental-friendly and energy-saving.
Specification:
| 5 Full Color Video LED Display Screen For Indoor Fixed Install | ||||||||
| S/N | Item | Technical Parameters | ||||||
| LED Parameters | ||||||||
| 1 | Item Name | LED Type | Brightness | Wave Length | H/V Visual Angle | |||
| 2 | Red LED | SMD2121 | 120-140mcd | 620-625nm | 140º/120º | |||
| 3 | Green LED | SMD2121 | 360-435mcd | 520-525nm | 140º/120º | |||
| 4 | Blue LED | SMD2121 | 80-100mcd | 470-475nm | 140º/120º | |||
| Module Specification | ||||||||
| 1 | Pixel Pitch | 5mm | ||||||
| 2 | Pixel Configuration | 1R1G1B | ||||||
| 3 | Module Resolution | 64 x 32 pixels | ||||||
| 4 | Module Pixles | 2048 pixels | ||||||
| 5 | Module Size | 320mm X 160mm | ||||||
| Cabinet Specification | ||||||||
| 1 | Cabinet Size(W X H X D) | 960mm x 960mm x 100mm | ||||||
| 2 | Cabinet Resolution(dot) | 192 x 192 pixels | ||||||
| 3 | Module Quanity (pcs) | 36pcs | ||||||
| 4 | Cabinet Pixels | 36864 pixels | ||||||
| 5 | Pixel Density | 40000 pixels/m2 | ||||||
| 6 | Cabinet Materials | Iron | ||||||
| 7 | Cabinet Weight | 31.5 kg per cabinet | ||||||
| 8 | Packaging | Wooden case | ||||||
| Whole Screen Specification | ||||||||
| 1 | Screen Brightness | ≥1200cd/m2 | ||||||
| 2 | Driving Method | 1/16 Scan | ||||||
| 3 | Best Viewing Distance | 5m - 40m | ||||||
| 4 | Max. Power Consumption | 800W/m2 | ||||||
| 5 | Average Power Consumption | 240W/m2 | ||||||
| 6 | Gray Level | 65536 levels(16 bit ) | ||||||
| 7 | Display Color | 16M | ||||||
| 8 | Frame Frequency | ≥60Hz | ||||||
| 9 | Refresh Frequency | ≥1920Hz | ||||||
| 10 | Uninterrupted Working Hours | ≥72 hours | ||||||
| 11 | Screen Life-span | ≥100,000 hours | ||||||
| 12 | MTBF | ≥5,000 hours | ||||||
| 13 | Discrete Blind Spot Rate | <1/10000 | ||||||
| 14 | Continuous Blind Spot Rate | None | ||||||
| 15 | Blind Spot Rate | <1/10000 | ||||||
| 16 | Protective Scale | For indoor use only | ||||||
| 17 | Screen Plainness | <±1mm | ||||||
| 18 | Power Supply Mode | AC220±10% 50Hz/AC110±10% 60Hz | ||||||
| 19 | Environment Temperature & Humidity | Temperature:-20 Celsius~+60 Celsius | ||||||
| Humidity:10%~90% RH | ||||||||
| 20 | Control Mode | Synchronous display with control PC by DVI | ||||||
| 21 | Control System | Linsn, Novastar or as you required. | ||||||
| 22 | Display Content | Video, DVD, VCD, TV, picture, cartoon, graphics, texts.etc. | ||||||
| 23 | Interface | Standard Ethernet | ||||||
| 24 | Transmission Distance | Multi mode fiber <500m, single mode fiber <30km,internet cable <100m | ||||||
| 25 | Certificate | CE, ROHS, FCC | ||||||
P5mm indoor Advertising LED Display
Applications:
Entertainment complexes, Churches, Restaurants, Showrooms, Casinos, Convenience Stores, Banking,
Government facilities, Theatres and Retail outlets etc.
Competitive Advantage:
Pre-producing:
1. Get complete requirements of clients.
2. To do a thorough analysis.
3. Offer a most reasonable and scientific solution.
4. Customized design.
In producing:
1. Producing progress updating for clients.
2. Provide Installation drawing for clients.
After service:
1. 2 years free maintenance.During this time, we will replace or repair our goods for free if there is something wrong with them.
2. 7 days a week, 18 hours a day on-line technical support for any clients by E-mail, call, Skype or other ways for free.
3. Free training for customers in factory which contains the operation training and maintenance training in the factory.
4. Local Installation Guidance Service. We also will send our engineers to your country by negotiation
