| IP Rationg (Front/Rear): | IP 65/IP54 | Expected Lifetime: | 100,000Hrs |
|---|---|---|---|
| Vertical Viewing Angle: | 140° | Brightess: | ≥6,500nits |
| Highlight: | led video display board,outdoor led panel |
||
Waterproof IP65 Front Service LED Display With Cold Steel Material Panel
Front Service LED Display Quick Detail:
1. Billboard advertising super brightness, waterproof IP65
2. Energy saving, easy maintenance
3. Advanced dot adjusting
4. Front flip maintaince, convenient Servicing
5. First-class LED chip
6. Long life time
Front Service LED Display Applications:
Commercial advertising,business establishments, Square, Road side, High way, Airport, Wharf, Hotel, Restaurant etc
Front Service LED Display Specifications:
| ODF-4 | ODF-8 | ODF-10 | |
| Physical Pitch | 4.81mm | 8mm | 10mm |
| Pixel Configuration | SMD1921 | SMD3535 | SMD3535 / DIP346 |
| Pixel Density | 43,264 pixels/sqm | 15,625 pixels/sqm | 10,000pixels/sqm |
| Module Dimensions (WXH)(mm) |
250X250 | 256X256 | 320X320 |
| Panel Dimensions(mm) | 1000X1000 | 1280X960 | 1280X960 |
| No. of Modules Per Panel(WXH) |
4X4 | 4X3 | 4X3 |
| Physical Resolution of Module(WXH) |
52X52 | 40X40 | 32X32 |
| Physical Resolution of Panel(WXH) |
208X208 | 160X120 | 128X96 |
| Panel Material | Cold Steel | Cold Steel | Cold Steel |
| Weight per panel (kg) |
65 | 79 | 79 |
| Processing | 16bit | 16bit | 16bit |
| Driving Method | 1/9 scan | 1/4 scan | 1/4scan or 1/2scan |
| Average Power Consumption |
250 W/panel | 360 W/panel | 360 W/panel |
| Refresh Rate | >1920Hz | >1920Hz | >1920Hz |
| Brightess | ≥5,500nits | ≥6,500nits | ≥6,500nits |
| Horizontal Viewing Angle |
140° | 160° | 160° /110° |
| Vertical Viewing Angle |
140° | 140° | 140° / 70° |
| Expected Lifetime | 100,000Hrs | 100,000Hrs | 100,000Hrs |
| IP Rationg (Front/Rear) |
IP 65/IP54 | IP 65/IP54 | IP 65/IP54 |
| Working Temperature | —20℃-50℃/—40℃-60℃ | —20℃-50℃ /10%-90% | —20℃-50℃ /10%-90% |
| Working Humidity | 10%-90%RH/10%-85%RH | —20℃-50℃ /10%-90% | —20℃-50℃ /10%-90% |
