Product Details:
Payment & Shipping Terms:
|
| Name: | Flexible LED Display | Physical Pitch: | 3mm |
|---|---|---|---|
| Pixel Configuration: | SMD2121 | Pixel Density: | 111,111 Pixels/sqm |
| Module Dimensions (WXH)(mm): | 240X120 | Color: | Full Color |
| Application: | Commercial Advertising / Animation | ||
| Highlight: | flexible led display screen,flexible led video screen |
||
Ultra Thin Flexible LED Display For Commercial Advertising / Animation
Flexible LED Display Quick Detail:
1, Flexible--- Flex is capable of flexing to conform to convex, concave or twisted surfaces unlocking endless potential for unique installations.
2, Ultra-thin --- Flex flexible LED tile is only 10mm depth.
3, Lightweight --- Flex LED tile is only 0.48 kg Per tile saving labor and transportation.
4, Low heat ---- power supply can be placed Max. 20m away from the LED screen body and keep LED screen lower heat and long lifespan.
Flexible LED Display Description:
1. Flexible and soft(Soft PCB board), the module,to some certain can be bent
2. Silicone mask,has good flatness.
3. With 10000 dots/m2 pixel density, can show HD video
4. Meet clients' various shape request(cylinder,bottle, curve, wave flower, torch etc)
5. Magnet install and front opening service, easy for assembling and maintain.
6. Large viewing angle up to 360 degree,not only meet clients' viewing requirement but also achieve
360 degree shooting angle.
Flex LED Panel Applications:
advertising, stage backdrop, stadium, business establishments,TV shows, car shows, mobile media, shopping center,exhibitions, fashion shows, concerts,Video, graphics,sports, entertainment, events,Stadium perimeter, etc
Flexible LED Display Specification:
| SPECIFICATION | ||
| FL-3 | FL-6 | |
| Physical Pitch | 3mm | 6.66mm |
| Pixel Configuration | SMD2121 | SMD3528 |
| Pixel Density | 111,111 pixels/sqm | 22,500 pixels/sqm |
| Module Dimensions (WXH)(mm) |
240X120 | 320X160 |
| Panel Dimensions(mm) | Customized | Customized |
| Physical Resolution of Module(WXH) |
80X40 | 48X24 |
| Weight | 8.2kg/sqm | 8.2kg/sqm |
| Processing | 16bit | 16bit |
| Colours | 281 trillion | 281 trillion |
| Contrast Ratio | 4,000:1 | 4,000:1 |
| Average Power Consumption |
10W | 10W |
| Max Power Consumption |
13W | 13W |
| Refresh Rate | >1920Hz | >1920Hz |
| Brightess | ≥1,000nits | ≥1,500nits |
| Driving Method | 1/40 | 1/8 |
| Horizontal Viewing Angle |
160° | 160° |
| Vertical Viewing Angle |
140° | 140° |
| Expected Lifetime | 100,000Hrs | 100,000Hrs |
| Servicing | Front | Front |
| IP Rationg (Front/Rear) |
IP 40 | IP 40 |
| Operation Temp/ Humidity |
—20℃-60℃ /10%-60% | —20℃-60℃ /10%-60% |
| Storage Temp/ Humidity |
—30℃-60℃ /10%-60% | —30℃-60℃ /10%-60% |
| Certification | CCC,CE,ETL,ROHS | CCC,CE,ETL,ROHS |
