Product Details:
Payment & Shipping Terms:
|
| Application: | Billboard Advertising | Protection Level:: | IP40 |
|---|---|---|---|
| Certification: | CCC,CE,ETL,ROHS | Servicing: | Front/Rear |
| Max Hanging: | 20/10 | Max Stacking: | 20/10 |
| Color: | Full Color | Feature: | Good Heat Emission Capability |
| High Light: | hire led screen,LED video wall rental |
||
Billboard Advertising Rental LED Display Screen Good Heat Emission Capability
Rental LED Display Screen Feature
1. ultra-light
2. Die -casting cabinets, high precision with seamless splicing
3. Standard cabinet size: 500x500mm, convenient for area calculation
4. Highly effective & quick for transportation and screen assembling
5. High brightness and be adjustable, meets the need of the changing requirement of customer in environment
Rental LED Display Screen Parameters
| SPECIFICATION | |||
| ORA-4 | ORA-5 | ORA-6 | |
| Physical Pitch | 4.81mm | 5.95mm | 6.25mm |
| Pixel Configuration | SMD2727 | SMD2727 | SMD2727 |
| Pixel Density | 43,264 pixels/sqm | 28,224 pixels/sqm | 25,600pixels/sqm |
| Module Dimensions (WXH)(mm) |
320X320 | 256X256 | 320X320 |
| Panel Dimensions(mm) | 500X500X75 /500X1000X75 | 500X500X75 /500X1000X75 | 500X500X75 /500X1000X75 |
| No. of Modules Per Panel(WXH) |
2X2 / 4X4 | 2X2 / 4X4 | 2X2 / 4X4 |
| Physical Resolution of Module(WXH) |
52X52 | 42X42 | 40X40 |
| Physical Resolution of Panel(WXH) |
104X104 /104X208 | 84X84 /84X168 | 80X80 /80X160 |
| Panel Material | Die-casting Aluminum | Die-casting Aluminum | Die-casting Aluminum |
| Weight | 9/15kg/panel | 9/15kg/panel | 9/15kg/panel |
| Processing | 16bit | 16bit | 16bit |
| Colours | 281 trillion | 281 trillion | 281 trillion |
| Contrast Ratio | 2,000:1 | 2,000:1 | 2,000:1 |
| Average Power Consumption |
75/150 W/panel | 75/150 W/panel | 75/150 W/panel |
| Max Power Consumption |
225/550W/panel | 225/550W/panel | 225/550W/panel |
| Refresh Rate | >1920Hz | >1920Hz | >1920Hz |
| Brightess | ≥6,000nits | ≥6,000nits | ≥6,000nits |
| Horizontal Viewing Angle |
160° | 160° | 160° |
| Vertical Viewing Angle |
140° | 140° | 140° |
| Expected Lifetime | 100,000Hrs | 100,000Hrs | 100,000Hrs |
| Servicing | Front/Rear | Front/Rear | Front/Rear |
| IP Rationg (Front/Rear) |
IP 65/IP54 | IP 65/IP54 | IP 65/IP54 |
| Operation Temp/ Humidity |
—20℃-50℃ /10%-90% | —20℃-50℃ /10%-90% | —20℃-50℃ /10%-90% |
| Storage Temp/ Humidity |
—20℃-50℃ /10%-90% | —20℃-50℃ /10%-90% | —20℃-50℃ /10%-90% |
Rental LED Display Screen Application:
Sports Stadium, Outdoor Signage and advertisement, Entertainment centers, Building facilities, Community centers, Amusement parks, Auto Parts and Maintenance shops etc.
Why choose BST
| 1. Our LED display signs have the ISO9001:2000 Quality System Certification; |
| 2. CE & RoHS Certification of our LED display signs; |
| 3. Excellent Technical Innovation; |
| 4. Contract Performance and Credibility; |
| 5. Price performance ratio; |
| 6. Modular LED display screens; |
| 7. LED displays with high brightness LED's; |
| 8. High ecperiences and know-how LED display products; |
| 9. Post sale assistance (after sale); |
| 10. Our LED display screens have a warranty up to 1-3 years (depending on configuration). |
| 11. Personalized sale and less than 24 hours response on all inquiries; |
