Product Details:
Payment & Shipping Terms:
|
| Name: | Outdoor Advertising LED Display | Protection Level:: | IP65 |
|---|---|---|---|
| Pixel Configuration: | SMD2727 | Pixel Density: | 43,264 Pixels/sqm |
| Feature: | High Brightness | Panel Dimensions(mm): | 1000X1000X150 |
| No. Of Modules Per Panel(WXH): | 4X4 | Color: | 281 Trillion Color |
| High Light: | High refresh rate LED Display Screen,Outdoor Advertising LED Display Screen,LED Display Screen for Shopping |
||
High refresh rate Outdoor Advertising LED Display Screen for Shopping LED wall
Outdoor Advertising LED Display Feature
1) Outdoor Advertising LED Display is very easy to calculate the size of LED screen. It can be exactly 4*3m, 6m*4m, 8m*4.5m etc. ( 4m*3m is 4:3 ratio and 8m*4.5m is 16:9 ratio, perfect to show video )
2) Ultra-thin and Super-light: only 50KG per cabinet of 960mmW*960mm and depth is only 130mm, can stand on floor independently.
3) Brightness can be automatically adjusted according to the real-time environmemt.
4) With specially designed fast lock system, easy to install and dismantle
5) High refresh rate over 1920Hz/S; wen you take photos or videos, no scaning lines, it can give you better visual experience.
Outdoor Advertising LED Display Parameters
| SPECIFICATION | ||
| OD-6 | OD-8 | |
| Pixel Configuration | SMD2727 | SMD3535 |
| Pixel Density | 22,500 pixels/sqm | 15,625 pixels/sqm |
| Module Dimensions (WXH)(mm) |
320X320 | 256X256 |
| Panel Dimensions(mm) | 1280X960X150 | 1280X768X150 |
| No. of Modules Per Panel(WXH) |
4X3 | 5X3 |
| Physical Resolution of Module(WXH) |
48X48 | 32X32 |
| Physical Resolution of Panel(WXH) |
192X144 | 160X96 |
| Panel Material | Steel / Aluminum | Steel / Aluminum |
| Weight(sqm) | 65/45 | 65/45 |
| Processing | 16bit | 16bit |
| Colours | 281 trillion | 281 trillion |
| Contrast Ratio | 2,000:1 | 2,000:1 |
| Average Power Consumption |
360 W/panel | 360 W/panel |
| Max Power Consumption |
900W/panel | 900W/panel |
| Refresh Rate | >1920Hz | >1920Hz |
| Brightess | ≥6,500nits | ≥6,500nits |
| Horizontal Viewing Angle |
160° | 160° |
| Vertical Viewing Angle |
140° | 140° |
| Expected Lifetime | 100,000Hrs | 100,000Hrs |
| Servicing | Front/Rear | Front/Rear |
| IP Rationg (Front/Rear) |
IP 65/IP54 | IP 65/IP54 |
| Operation Temp/ Humidity |
—20℃-50℃ /10%-90% | —20℃-50℃ /10%-90% |
| Storage Temp/ Humidity |
—20℃-50℃ /10%-90% | —20℃-50℃ /10%-90% |
Outdoor Advertising LED Display Application:
Commercial advertising,Stadium perimeter, such as banks,schools, telecommunications, mobile media, night club, business establishments, customs, stadiums, studio, stock exchange centers, bus station, shopping malls, railways, airports, harbors, etc;
1. Provides all LED display relative solution, like installation drawing etc.
2. Have free training about how to use and maintain LED display with our professional engineer.
3. Provide free spare parts for future urgent need.
4. Technical Support: We could send our engineer to guide the installation for you. But the relevant cost should be paid by your esteemed company such as accommodation & round-trip ticket.
5. Professional engineer in service after sales, 18/7 for any inquiry.
6. All other service request will be considered in BST , please contact with sales in details.
Why choose BST
| 1. Our LED display signs have the ISO9001:2000 Quality System Certification; |
| 2. CE & RoHS Certification of our LED display signs; |
| 3. Excellent Technical Innovation; |
| 4. Contract Performance and Credibility; |
| 5. Price performance ratio; |
| 6. Modular LED display screens; |
| 7. LED displays with high brightness LED's; |
| 8. High ecperiences and know-how LED display products; |
| 9. Post sale assistance (after sale); |
| 10. Our LED display screens have a warranty up to 1-3 years (depending on configuration). |
| 11. Personalized sale and less than 24 hours response on all inquiries; |
