Product Details:
Payment & Shipping Terms:
|
| Pixel Pitch: | 4mm | Pixel Configuration: | 1R1G1B |
|---|---|---|---|
| Material: | Steel Iron/Aluminum | Brightness: | >1400nits/sqm |
| Cabinet Size: | 768mmX768mm | LED Type: | SMD2121 |
| Color: | Full Color | ||
| High Light: | advertising led display screen,led wall display screen |
||
Aluminum Alloy / Steel Giant P4 SMD2121 indoor Advertising LED Screen For Airport
Quick Detail:
1. High debugging brightness and no damage to gray scale, achieving the debugging technology for nice image
2. High brightness: > 1400cd/㎡,and can be adjusted, the screen can be adapted in any condition by adjusting the brightness.
3. High refresh rate: > 1500HZ,Pictures and video can be played very clearly and vividly
4. Each lamp can be repaired, and easy to repair. The cost of maintenance will be reduced
5. Perfect quality and stability, 24/7 running
6,commendable solve the problem of the mosaic, have the excellent consistency of light
7,Humanized operating interface with breakdown indicator lights, easy to maintain.
Specification:
| Indoor SMD Fixed Installed Commercial LED Displays | |||||
| Module | Pitch/mm | P3 | P4 | P5 | P6 |
| Module size/mm | 192x96 | 128x128 | 160x160 | 192x192 | |
| Density of pixel/(dots/m2) | 111111 | 62500 | 40,000 | 27,777 | |
| Pixel composition | SMD 3 in 1 | SMD 3 in 1 | SMD 3 in 1 | SMD 3 in 1 | |
| Led encapsulation | SMD2121 | SMD2121 | SMD3528 | SMD3528 | |
| Resolution of module | 64x32 | 32X32 | 32X32 | 32X32 | |
| Main | Optimum viewing distance | 3-10m | 4-15m | 6-16m | 7.5-20m |
| View angle / ° | 140H,140V | 140H,140V | 140 H,140 V | 140 H,140 V | |
| Max power consumption/W/M2 | 700 | 700 | 700 | 700 | |
| Size of cabinet/mm | 768x768 | 768X768 | 960X960 | 960X960 | |
| Resolution of cabinet | 256x256 | 192X192 | 192X192 | 160x160 | |
| Driving method | 1/16 scan constant current | 1/16 scan constant current | 1/8 scan constant current | 1/8 scan constant current | |
| Refresh rate Hz/S | ≥1500 | ≥1500 | ≥1500 | ≥1500 | |
| Luminance of white balance | ≥1500 nits | ≥1500 nits | ≥1500 nits | ≥1500 nits | |
| Thickness | 120mm | ||||
| Operation of Environmental Temperature/℃ | below 30 to above 60 | ||||
| Working voltage | 110-220 VAC/+/- 10% | ||||
| Grey scale/color | displaying colors≥16.7M(synchronized) | ||||
| Brightness adjustment | 4096 levels of each color(manually),100 levels of each color(automatically) | ||||
| Input signal | RF,S-Video,RGB,RGBH,YUV,YC&Composition ,etc | ||||
| Control system | linsn(sending card,receiving cards and Hubs) | ||||
| Average of non-failure life | >50,00h | ||||
| Life span | >100,000h | ||||
| Functionless dot rate | <0.0001 | ||||
Description:
1. Easier maintainence, High resolution, Good contract, Less Weight, easy to install. can be useful any indoor advertising, such as showroom, meeting room, hotel, Restaurant, matro etc place.
2. Can automatic to adjustable the brightness as to ensure different environment.
3. Higher resolution can make HD with 4K effect Video.
4. We make best design with high cost- efficiency according to the actual needs of our customers.
5. we can offer OEM as client's required.
6,Jointed correctly, being installed & dismounted by one person without tool.
Applications:
indoor mobile media,Commercial advertising, night club, business establishments, such as banks, stock exchange centers, bus station, schools, telecommunications, customs, stadiums, studio, shopping malls, railways, airports, harbors, government, video conference, etc;
Competitive Advantage:
1. Intelligent operation,Good heat dissipation function.
2. Standard cabinet design, makes stocking, transportation, construction, spare parts and maintenance easier and simplely.
3. widely view angles ( More than 140degrees ) & Extremely close view distances .
4. Pure color, brilliant colors, breathtaking grayscale,high contrast level, High color saturation, Better display performance
5,We provide the technology training for free, which contains the operation training and maintenance training in the factory.
6,We provide the operation manual, software, test report and so on
7,Customized design is available,OEM & ODM are welcomed.
8,Exclusive and unique solution can be provided to our customer by our well-trained and professional engineers and staffs
