Product Details:
Payment & Shipping Terms:
|
| High Light: | led display sign,outdoor led panel |
||
|---|---|---|---|
HD 16mm Front Service Digital Led Display Board Programming / Led Advertising Signs
Characteristics:
-- Super bright > 6500CD
-- Easy to maintain and operation
-- 24 months warranty and long term free tech-support
-- High contrast ratio, high refresh rate
-- Excellent color and brightenss uniformity
-- Available models: P6, P8, P10, P16, P20mm
Application:
Stadium perimeter,business establishments,Commercial advertising, mobile media,, such as banks, bus station, telecommunications, customs, shopping malls,schools,stadiums, studio, airports, harbors,railways,stock exchange centers,etc;
Quick Detail:
-- Waterproof IP65
-- First-class Components, stable quality
-- Energy saving
-- Nature vivid image
-- Long lifespain> 100,000 hours
-- Light weight and easy to install
| BST-OFS-16 (Pitch 16mm outdoor full color) | |
| Technique | DIP346 |
| Pixel structure | 1R1G1B |
| Pixel pitch | 16mm |
| Pixel density | 3906 dots/㎡ |
| Luminance | 6,500 cd/㎡ |
| Module dimension | 320mm(W) * 320mm(H) |
| Module resolution | 20 pixel(W) * 20 pixelmm(H) |
| Cabinet dimension | 1280 * 960mm |
| Cabinet resolution | 80 * 60 |
| Cabinet area | 1.228 sq.meter |
| Optimal visual distance | >16m |
| Visual angel | 120 degree (H) 70degree (V) |
| Max power consumption | ≤1000w / ㎡ |
| Average power consumption | ≤500w / ㎡ |
| Brightness adjustment | Adjust according to the enviroment |
| brightness software (0%-100%adjustable) | |
| Gray scale | point by point 4096 gray gradelevels of |
| each color,16 bits γ correction avilable | |
| Drive mode | static drive, constant current |
| Frame frequency | ≥60HZ |
| Refresh frequency | ≥1500HZ |
| Input voltage | AC110/220 volts |
| Operation temperature | ﹣40℃~ +60℃ |
| Operation humidity | 10％～90％ |
| Input signal | S-video, RF, RGB, Yuv, YC, composite… |
| Control system | DVI card + master control card + receiver card |
| MTBF | >5000 hrs |
| Life span (50% brightness) | 100,000 hrs |
| Malfunction dot rate | 1/10000 |
| Ingress protection rate | IP65(front side), IP54 (back side) |
| Installation | Wall mount, and stand structure |
