Product Details:
Payment & Shipping Terms:
|
| Pixel Pitch: | 6mm | Pixel Configuration: | 1R1G1B |
|---|---|---|---|
| Led Type: | SMD3528 | Cabinet Size: | 960mm X 960mm |
| Control System: | Linsn | Color: | Full Color |
| Brightness: | > 2000nits/sqm | ||
| High Light: | advertising led display screen,led wall display screen |
||
1/8 Scan P6 SMD3528 RGB 16bit Indoor Advertising Led Display 2000 Cd/M2
Quick Detail:
1. High brightness more than 2000nits/sqm
2. Aluminum cabinet with Light weight
3. Intelligent oprate control system
4. Can play different formats of image files, flash, video signal from TV, video and other equipments.
5. High referesh rate more than 1500HZ
6.With good lightening accordance and no mosaic.
7.High brightness, and can be adjustable, meets the needs of customer's requirements.
8.Uses real pixels rather than virtual pixcels, better viewing effect .
Description:
1. High definition and high brightness
2. Long durability and high reliability
3. Advance video control system and super input system
4. Audio and video interface of the system can offer vivid, complete and high quality LED display to TV broadcasting signal
5. Fits for various computer net
6. Standard connection socket
7. Easy installation, low maintenance cost
8. Software for remote control of communication and scheduling
9. Good heat emission capability
Our Service:
1)Reply your inquiry in 24 hours.
2)Experienced staffs answer all your query in fluent English,Spanish,Russian,etc
3)Customized design is available,OEM & ODM are welcomed.
4)Exclusive and unique solution can be provided to our customer by our well-trained and professional engineers and staffs.
5)Special discount and protection of sales area provided to our led display distributor.
6)Warmly welcome your visit in our company if available
7)We provide warranty of all components for 24 months. During this time, we will replace or repair our goods for free if there is something wrong with them.
8)Guidance service: We can guide on line if customers have questions about the installation and usage. For large project, we provide your engineer a week free training, or if customer could bear the relevant cost, our engineer can go to customer’s country for on-site guidance.
9)We provide the technology training for free, which contains the operation training and maintenance training in the factory.
10)We provide the operation manual, software, test report and so on.We also provide lifetime consultation by E-mail, call, Skype or other ways for free
Specification:
| Display and control feature | Structure feature | ||
| Specification | Parameter | Specification | Parameter |
| Pixel Pitch | 6mm | Module size | 192mm*192 mm |
| Pixel composing | 1R1G1B | Display resolution/module | 32 dots*32 dots |
| Wavelength (R) | 625±5 | Standard cabinet size | 960 mm*960 mm |
| Wavelength (G) | 522±3 | Weight per sqm | 27 Kg/sqm |
| Wavelength (B) | 567±3 | Protection classification | IP43 |
| Wave Angle (H) | 140°(H)/ 140°(v) | Install mode | Wallmount, hung and stand structure |
| LED package | SMD3528 | Cabinet Material | Iron/Aluminum |
| Density per sqm | 27776 pixel | Working power | |
| Display color | 256*256*256 | Specification | Parameter |
| Whiteness brightness | ≥1000 | Working voltage | AC 110v/220v±10% 50~60Hz |
| Brightness level | 256 grade | Max power/sqm | 600W/sqm |
| Frame frequency | 60 Hz | Average power/sqm | 200W/sqm |
| Refresh | >1920 Hz | Short circuit protection | Yes |
| Driving method | 1/8 Constant Driving | Led Lamp type | Nichia/Cotco/Cree/Axt/Silan/Taiwan |
| Control mode | synchronous | Working environment | |
| Display port | DVI | Specification | Parameter |
| Display mode | 1280*1024 | Environment | Indoor |
| Out of control | 2/10,000 ( scattered) | Working temperature | --20~60°C |
| lifetime | 100,000 hours | Working Humidity | 10~90% |
Our indoor LED screens are available with the following pixel pitch options:
1.6mm, 1.9mm, 2.5mm, 3mm, 3.91mm, 4mm, 4.8mm, 5mm, 6mm, 6.25mm, 7.62mm, 10mm
The smaller the pixel pitch (distance between each pixel) the higher the resolution and closer the viewer
can be stood to the screen. Each of our indoor LED screens are shipped in module format allowing you the flexibility to create screens of any size. Options for front or rear service access are available depending on your installation.
P1.6 led display for the best viewing distance between 2-5m
P1.9 led display for the best viewing distance between 2-6m
P1.9 led display for the best viewing distance between 2-6m
P2.5 led display for the best viewing distance between 2.5-8m
P3 led display for the best viewing distance between 3-10m
P4 led display for the best viewing distance between 4-15m
P5 led display for the best viewing distance between 5-20m
P6 led display for the best viewing distance between 6-25m
P8 led display for the best viewing distance between 8-30m
P10 led display for the best viewing distance between 10-33m
P12 led display for the best viewing distance between 12-40m
P16 led display for the best viewing distance between 15-45m
P20 led display for the best viewing distance between 18-60m
P25 led display for the best viewing distance between 20-70m
P31.25 led display for the best viewing distance between 25-100m
