1/8 scan P5mm SMD indoor Commercial Advertising led display screen / Vedio / Picture

1/8 scan P5mm SMD indoor Commercial Advertising led display screen / Vedio / Picture

Quick Detail:

1. High Density

2. Supper Clarity & Low Gray Level

3. Energy Saving for High Efficiency

4. Large Viewing Angle

5. High Uniformity and clear image can bring you a vivid audio visual effect

6. High Reliability

7. Excellent Color Mixing

8. Easy for assembling and connection with the connector added.

Description:

1. SMD3-IN-1 technology are used for indoor LED display
2. wide view angle:140 inhorizonal and 140 in vertical
3. special design and advanced SMT technology improves the heat dissipation
4. with high fresh rate controller, guarantee that no scan line when taking photos
5. regular shape and special shape(such as curve,round) can be designed
6. easy for assembleing and connection with the connector added
7. high color uniformity and clear image can bring you a vivid audio visual effect
8. both front access and rear access areavailable

Competitive Advantage:

1. Two years quality warranty with lifelong maintenance.

2.  Free guarantee repair (including labor and material): free for repair service in quality warranty period and reasonable charge for spare parts and maintaining service after the quality warranty period. Never exempt our responsibilities on product owned defects.
3. Spare Parts and free CAD drawing: necessary spare parts are provided together with products to customers.
4. Free Technical Training: integrative and normative technology training is available for free to technical personnel from customer, to ensure trainees to be skilled in regular operation of hardware and software of the products, and be able to estimate and solve small problems.

 5. Customer Investigation: our after-sales team will telephone or e-mail user every month in warranty period to follow up the working condition of the products, and to discover problem and solve the problem instantly.
 6. Software Upgrade: lifelong maintenance of control system, incessant improvement on the system functions and unending software upgrades.
7. Site Instruction Service of installation is available.

Specification:

LED Parameters

Item	Luminous Intensity	Viewing Angle(H/V)	Wavelength	Test Condition
Red LED	150-200mcd	140º/140º	620-630nm	25℃,20mA
Green LED	260-330mcd	140º/140º	520-535nm	25℃,20mA
Blue LED	55-65mcd	140º/140º	465-475nm	25℃,20mA

Module Parameters

Pixel Pitch	5mm
Pixel Configuration	1R1G1B SMD2121 3in1
Module Resolution	32dots*32dots for real
Module Pixels	1024 dots
Module Size	160mm*160mm
Module Weight	0.3KG

Cabinet Parameters

Cabinet Size(W*H*D)	960*960*100(mm) or Customized
Cabinet Resolution	192dot*192dot for real
Module Quantity	36 pcs
Cabinet Pixels	36864 dots
Pixel Density	40000 dot/sqm
Avg. Power Consumption	200W/sqm
Max. Power Consumption	600W/sqm
Material	Iron or Aluminum
Cabinet Weight	30KG for iron cabinet; 20KG for aluminum cabinet
