Product Details:
Payment & Shipping Terms:
|
Warranty: | 2years | Driving Method: | 1/16 Scan, Constant Current |
---|---|---|---|
Package: | Wooden Case | Brightness: | 800nits /sqm |
Cabinet Size: | 480X480mm | Module Size: | 240X240mm |
Highlight: | indoor full color led display,LED Video Wall Screen |
Lightweight P2.5 SMD2121 Indoor Full Color Led Screen With 140° H / 140° V viewing angle
Products Feature:
1. Light Weight:Using aluminum profile material, the cabinet weight is only 7 kg.
2. High Contrast Ratio: novel design of mask,contrast ratio can reach 1800.
3. Quiet:Direct current fan only has little noise
4. Thin:the thickest part of cabinet is only 65mm.
5. High Precision:each cabinet of precision deviation <0.2mm.
6. High Refreshing:Usually it can reach 800Hz,but it can reach 1800Hz if you use appropriative IC.
7. Convenient and Fast Installation.
8. Best Cabinet Size: 480mm*480mm.
9. Maintenance principles: response in time, solve problems as soon as possible and ensure the use.
10. Maintenance terms: In the Maintenance period, free of all maintenance charges. Under normal use and storage,our company will be responsible for the equipments. If there is any failure in product quality, our company will maintain and change the components for free. After Maintenance period, only charge the material costs fees free of manual work fees
Applications:
Wide Applicability: Stage rental events, entertainment, indoor and outdoor environment.
Specification:
| |||
Pixel Pitch (mm) | 2.5 | ||
LED Type | SMD | ||
Pixel Density (pixel/sq.m.) | 277008 | ||
Viewing Angle (H/V) | 140° / 140° | ||
Brightness(cd/sq.m.) | 1000 | ||
Refresh Rate(Hz) | 1920~4800 | ||
Optimized Viewing Distance (m) | 2.5~30 | ||
Average Power Consumption (W/sq.m.) | 272 | ||
| 680 | ||
Input Voltage | AC110V or AC220V±10% 50/60Hz | ||
Module Size in Pixel (W×H) | 96×96 | ||
Module Size in mm (W×H) | 240×240 | ||
Panel Size in Pixel (W×H) | 480×480 | ||
Panel Size in mm (W×H×D) | 480×480×80 | ||
Weight (kg/Panel.) | 7 | ||
IP Rating | IP40 | ||
Maintenance | Rear | ||
Operating Temperature | -10℃ ~40℃ | ||
Operating Humidity | 10~80RH% |
Ultral HD P2.5mm indoor full color LED Display
FAQ
1. How can i place an order?
Please provide the details of your requirements as clear as possible. So we can send you the offer at the first time.
1)It will use for what ?
2)where will you install it ?
3)full color or single color?
4)It's rental installation or fixed installation ?
For designing or further discussion, it is better to contact us with Skype, in case of any delays.
2. What kind of display we provide?
We have indoor/outdoor/led curtain/mobile LED /rental LED display/LED stage/LED DanceFloor/Irregular LED display for you choose.
3. What about the lead time for order ?
Always: 15-20 working days
4.How about the warranty?
We have 2years warranty and lifelong maintenance
5. What is your terms of delivery?
We accept EXW, FOB, CFR, CIF, DDU, DDP, etc. You can choose the one which is the most convenient or cost effective for you.
