Product Details:
Payment & Shipping Terms:
|
| Product Name: | P7.62mm Indoor Led Curtain Display | Pixel Picth: | 7.62mm |
|---|---|---|---|
| LED Type: | SMD3528 | Density: | 17222 |
| Module Size: | 305mmX366mm | Panel Size: | 610mmX732mm |
| High Light: | led curtain screen,led stage curtain |
||
Waterproof P7.62 Flexible Led Curtain Display , Stage Backgrond Led Screen
Quick Detail:
1, Accurate color uniformity and smoother, flicker-free video
2. Low noise generation and high cost-performance ratio
3. Cabinet connection angle can be adjusted by -15 degree to +15 degree
4. Light weight and super transparency ratio
6. Fast Lock System & No Fan Design
Parameters of BST-IRC-7.62
|
Model No. |
IRC |
|
Pixel Pitch |
7.62mm |
|
Module Size |
305mm*366mm |
|
Module Resolution (W*H) |
40 dots*48 dots |
|
Pixel Density |
17222 dots/ ㎡ |
|
LED Type |
SMD 3528 |
|
Pixel Configuration |
1R1G1B |
|
Wavelength (R.G.B) |
R:625±2nm G:525±2nm B:470±2nm |
|
Drive Mode |
Dynamic 1/8 Duty Constant Current |
|
Cabinet Size |
610×732×75mm |
|
Cabinet Resolution |
80dots×96dots |
|
Brightness |
≥1500cd/㎡ |
|
Contrast |
≥2000:1 |
|
Viewing Angle |
140°(Horizontal )/140°(Vertical ) |
|
Best Viewing Distance |
7m-300m |
|
Grey Scale |
10bits/1024levels |
|
Color Capability |
16777216 |
|
Color Temperature |
5000-9300K |
|
Maximum Power Consumption |
500 W/m2 |
|
Average Power Consumption |
200 W/m2 |
|
Working Voltage |
AC 220V/110V s±15% 50-60 HZ |
|
Frame Frequency |
60-85 HZ |
|
Refresh Frequency |
240 - 1000HZ |
|
Brightness Correction |
Pixel, Module, Cabinet Correction |
|
Operating Temperature |
-40~+65℃ |
|
Operating Humidity |
10-90% RH |
|
LED Lifespan |
100,000 hours |
|
MTBF |
≥50,000 hours |
|
Computer Operation System |
Win 98/ Win XP/ Win 2000/Win 7/Win 8 |
|
Video Signal Input |
RF,S-Video, RGB,RGBHV,YUV,YC,VGA, DVI, HDMI, SDI,HD-SDI ,Composite |
|
Video Signal Output |
RF, S-Video, RGB, RGBHV, YUV, YC etc. |
|
Graphics Card |
DVI Graphics Card |
|
Control Distance |
LINSN / NOVA / DB-STAR |
|
Software |
LED studio 10.0 |
|
Waterproof Level |
IP65(Front Side), IP54 (Back Side |
|
Installation |
hung and stand |
|
Out of Control Rate |
0.01 % |
Application:
Stadium perimeter,weddings, openings, promotions customs, stadiums, studio, railways, airports, harbors, shopping malls, such as banks,schools, telecommunications, night club, business establishments, entertainment events,mobile media, bus station,Commercial advertising, stock exchange centers,etc;
Description:
1. Most user-friendly stage LED screen
2. Smart cabinet with lock design, ensuring fast maintenance during the event
3. Angle-adjustable connection parts between cabinets; each cabinet side with 7.5 degree curved angle
4. Multiple usage of one screen possible
5, Excellent heat release performance
